產品特點:
1.機架消除應力后，整機一次裝夾加工完成，精度高。
2.采用電子—液壓比例伺服同步，行程內可任意點控制，重復精度達±0.01mm，平行度達±0.01mm。
3.標準數控系統采用荷蘭Delem DA-52，可選用DA-53、DA-56、DA-65W 、DA-66W 、DA-66T、DA-69T，也可選用瑞士CYBELEC公司的專用數控系統；數控系統、光柵尺、液壓閥均原裝進口。
4.工作臺采用機械斜楔式自動撓度補償系統（V軸），補償量由數控系統自動設定，解決了滑塊在折彎過程中變形對工件質量的影響，保證了全長折彎角度的一致，使工件的直線度達到更高。
技術參數：
|
W67Y/K Series NC AND CNC Hydraulic bending machine |
|
Specification |
Nominal press
（KN） |
Length of workbench
（mm） |
Throat depth
（mm） |
Ram stroke
（mm） |
Number of stroke
（min-1） |
Motor power
（KW） |
|
WC67Y/K-40/2500 |
400 |
2500 |
200 |
100 |
11 |
4 |
|
WC67Y/K-50/2500 |
500 |
2500 |
200 |
100 |
11 |
5.5 |
|
WC67Y/K-63/2500 |
630 |
2500 |
250 |
100 |
10 |
5.5 |
|
WC67Y/K-63/3200 |
630 |
3200 |
250 |
100 |
10 |
5.5 |
|
WC67Y/K-80/2500 |
800 |
2500 |
320 |
150 |
8 |
7.5 |
|
WC67Y/K-80/3200 |
800 |
3200 |
320 |
150 |
8 |
7.5 |
|
WC67Y/K-100/2500 |
800 |
2500 |
320 |
150 |
8 |
7.5 |
|
WC67Y/K-100/3200 |
1000 |
3200 |
320 |
150 |
8 |
7.5 |
|
WC67Y/K-100/4000 |
1000 |
4000 |
400 |
150 |
8 |
7.5 |
|
WC67Y/K-125/2500 |
1250 |
2500 |
320 |
150 |
8 |
7.5 |
|
WC67Y/K-125/3200 |
1250 |
3200 |
320 |
150 |
8 |
7.5 |
|
WC67Y/K-125/4000 |
1250 |
4000 |
400 |
150 |
8 |
7.5 |
|
WC67Y/K-160/3200 |
1600 |
3200 |
400 |
180 |
8 |
11 |
|
WC67Y/K-160/4000 |
1600 |
4000 |
400 |
180 |
8 |
11 |
|
WC67Y/K-160/5000 |
1600 |
5000 |
400 |
180 |
7 |
11 |
|
WC67Y/K-160/6000 |
1600 |
6000 |
400 |
200 |
7 |
15 |
|
WC67Y/K-200/3200 |
2000 |
3200 |
400 |
200 |
7 |
15 |
|
WC67Y/K-200/4000 |
2000 |
4000 |
400 |
200 |
7 |
15 |
|
WC67Y/K-200/6000 |
2000 |
6000 |
400 |
200 |
7 |
15 |
|
WC67Y/K-250/3200 |
2500 |
3200 |
400 |
200 |
7 |
18.5 |
|
WC67Y/K-250/4000 |
2500 |
4000 |
400 |
200 |
7 |
18.5 |
|
WC67Y/K-250/6000 |
2500 |
6000 |
400 |
250 |
7 |
18.5 |
|
WC67Y/K-300/3200 |
3000 |
3200 |
400 |
250 |
7 |
22 |
|
WC67Y/K-300/4000 |
3000 |
4000 |
400 |
250 |
7 |
22 |
|
WC67Y/K-300/6000 |
3000 |
6000 |
400 |
250 |
7 |
30 |
|
WC67Y/K-300/7000 |
3000 |
7000 |
400 |
250 |
7 |
30 |
|
WC67Y/K-400/6000 |
4000 |
6000 |
400 |
250 |
7 |
30 |
|
WC67Y/K-500/6000 |
5000 |
6000 |
400 |
300 |
7 |
37 |
|
WC67Y/K-600/6000 |
6000 |
6000 |
420 |
300 |
7 |
37 |
|
Because in the continuous improvement of products, if there is difference between this date and technical data, should comply with the technical agreement parameters on both sides. No further notice! |
